Cutter Crusher
Suitable Excavator:
15-40tonCustomized service, meet specific need
Product Features
✪ The unique design and innovative method of multifunctional hydraulic shear ensure efficient operation and strong cutting force.
✪ The multifunctional hydraulic shear adopts special jaw size and special blade design to,improve elongation.
✪ The powerful hydraulic cylinder greatly enhances the closing force of the jaw, enabling it to cut the hardest steel.
A cutter crusher is a heavy-duty demolition attachment designed to cut steel and crush concrete efficiently in construction and recycling work
Specification
Metric
Imperial
CC285~385
| Model | Unit | CC285 | CC385 |
| Max Opening | mm | 853 | 911 |
| Height | mm | 2355 | 2706 |
| Width | mm | 1464 | 1772 |
| Weight | kg | 2700 | 4360 |
| Working Pressure | bar | 250-280 | 280-320 |
| Working Flow | l/min | 160-190 | 200-230 |
| Excavator | ton | 20-22 | 25-30 |
CC285~385
| Model | Unit | CC285 | CC385 |
| Max Opening | inch | 33.6 | 35.9 |
| Height | inch | 92.7 | 106.5 |
| Width | inch | 57.6 | 69.8 |
| Weight | lb | 5952.5 | 9612.2 |
| Working Pressure | psl | 3626-4061 | 4061-4641 |
| Working Flow | gpm | 42-50 | 53-61 |
| Excavator | lb | 44092-48502 | 55116-66139 |
